CBD30X Electric Pallet Truck
Modol: CBD30X Electric Pallet Truck

Double-cylinder structure design 3 tons load-bearing stable electric pallet truck

  • Double oil cylinder structure design, smoother load-bearing
  • Reinforced front wheel frame, customised front wheels, greater load carrying capacity, self-lubricating bushings, which improved axle life; US Curtis controller, low failure rate, powerful performance, smoother operation.
  • Vertical drive, strong power, unique and compact structure, large load capacity, low steering resistance, smooth load, good self-locking, high rotating torque, reliable operation and easy to install and maintain.
  • Large capacity battery for continuous operation for up to 4 hours at full load and up to 6-8 hours for daily use, easily meeting the daily handling workload.
  • The OMRON large level switch, with adjustable limit plate, is of stable quality and more reliable in use.
  • Parameters
  • Assembly Diagram
  • Contact
  • Model

    Unit

    CBD30X

    Basic







    Rated load

    Q(Kg)

    3000

    Load centre distance

    C(mm)

    600

    Lifting method



    Electric Electric

    Operating method



    WalkingWalkie

    Wheels











    Material



    PU

    Wheelbase

    Y(mm)

    1380/1450

    Number of drive/balance/weight-bearing wheels



    1x+2/4

    Load-bearing wheel size

    mm

    ①80x70

    Drive wheel size

    mm

    ①230x75

    Balancer wheel size

    mm

    ①75x46

    Dimensions





















    Minimum fork height

    Mm)

    85

    Max. fork height after lifting

    h3(mm)

    200

    Outside fork width

    mm

    560/685

    Inside fork width

    b5(mm)

    200/325

    Fork size(l*e*s)

    mm

    1150*160*50/1220*160*50

    Aisle width, pallet1000x1200

    mm

    2305/2375

    Aisle width, pallet800x1200

    mm

    2355/2375

    Overall vehicle length

    LJmm)

    2055/2125

    Overall width

    b1(mm)

    690

    Overall height

    h14(mm)

    1215

    Min. turning radius

    Wa(mm)

    1540/1610

    Performance









    Maximum travel speed (full/no load)

    km/h

    4/5

    Max. lifting speed (full/no load)

    mm/s

    10/13

    Maximum descent speed (full/no load)

    mm/s

    14/10

    Fast/Slow speed adjustment function



    Yes

    Climbing degree (full/no load)

    %

    W4/W6

    Electrical









    Drive mode



    AC

    Drive motor

    Kw

    24V2.5

    Lifting motor

    Kw

    24V0.8

    Battery capacity

    V/Ah

    24V/165

    Charger type



    24V30A

    Weight



    Battery weight

    Kg

    155

    Self-weight

    Kg

    460

    *We reserve the right to change product design and specifications without prior notice.
