CBD20X Electric Pallet Truck
Modol: CBD20X Electric Pallet Truck

2 ton load electric pallet truck

  • Integrated structure of the circuit board: neat appearance, easy to install and maintain, saving installation and maintenance time.
  • Adopted Omron large travel switch for more stability.
  • The installation position has been optimised and the travel switch has been re-selected for more stable and reliable performance. Control power supply, taking power from the controller, which has an internal isolation circuit to avoid interference.
  • When the battery voltage falls below 30%, the power unit will not start, effectively protecting the motor and battery of the power unit, improving the life of the battery and motor.
  • The housing material is made of 52 sheets, which reduces the size and makes it easier to install and more robust, effectively avoiding the occurrence of shell breakage.
  • Open skeleton structure, more simple and beautiful appearance. Easy to install and maintain.
  • Hollow lift rod, cylinder head external thread sealing, more reasonable structure, more stable performance, reduce the failure rate.
  • Parameters
  • Assembly Diagram
  • Contact
  • Model

    Unit

    CBD20X

    Basic

    Rated load

    Q(Kg)

    2000

    Load centre distance

    C(mm)

    600

    Lifting method



    Electric

    Operating method



    Walking

    Wheels

    Material



    PU

    Wheelbase

    Y(mm)

    1230/1300

    Number of drive/Balance/Weight-bearing wheels



    lx+2/4

    Load-bearing wheel size

    mm

    Medium80x70

    Drive wheel size

    mm

    Medium210x75

    Balancer wheel size

    mm

    Medium75x46

    Dimensions

    Minimum fork height

    h13(mm)

    85

    Max. fork height

    mm

    200

    Max. lifting height

    ha(mm)

    115

    Outside fork width

    b5(mm)

    560/685

    Inside fork width

    b11(mm)

    240/365

    Fork size(l*e*s)

    l(mm)

    1150*160*50/1220*160*50

    Aisle width, pallet1000x1200

    mm

    2085/2155

    Aisle width, pallet800x1200

    mm

    2135/2155

    Overall vehicle length

    L(mm)

    1650/1720

    Overall width

    bi(mm)

    685

    Overall height

    hi4(mm)

    1220

    Min. turning radius

    Wa(mm)

    1385/1455

    Performance

    Travel speed (full/no load)

    km/h

    4/5

    Lifting speed (full/no load)

    mm/s

    25/30

    Descent speed (full/no load)

    mm/s

    30/20

    Fast/Slow speed adjustment function



    Yes

    Climbing degree

    %

    W4

    Drive mode



    DC

    Electrical

    Drive motor

    V/Kw

    24V0.75KW

    Lifting motor

    V/Kw

    24V0.8KW

    Battery capacity

    V/Ah

    2x12V/100Ah

    Charger type

    V/A

    24V12A

    Weight

    Battery weight

    Kg

    24

    Self-weight

    Kg

    230/245

     *We reserve the right to change product design and specifications without prior notice.
