Home / Products / Hydraulic Pallet Truck / SYP-III Hydraulic Pallet Truck
SYP-III Hydraulic Pallet Truck
Modol: SYP-III Hydraulic Pallet Truck

Small volume welded oil pump hydraulic pallet truck

  • Small-volume welded oil pump, the vehicle design is light and economical;
  • Extremely strong light steel structure, easy to operate, high reliability;
  • Reliable oil leakage prevention hydraulic system, the shell seat is an integrated design of mechanical and hydraulic, maintenance-free, free disassembly.
  • Parameters
  • Assembly Diagram
  • Contact
  • Rated load

    Kg

    2000

    2000

    Minimum fork height

    H(mm)

    75

    85

    Maximum height after fork lift

    H1(mm)

    190

    200

    Max. lifting stroke

    mm

    ≥115

    ≥115

    Outside width of forks

    B(mm)

    450/520/550/685

    450/520/550/685

    Inside fork width

    mm

    150/220/250/385

    150/220/250/385

    Fork working length

    L(mm)

    900/1150/1220

    900/1150/1220

    Single fork width

    e(mm)

    150

    150

    Fork thickness

    s(mm)

    50

    50

    Overall vehicle length

    L1(mm)

    1273-1593

    1273-1593

    Overall vehicle width

    mm

    450/520/550/685

    450/520/550/685

    Overall vehicle height

    H2(mm)

    1125

    1125

    Cylinder lift rod diameter

    mm

    Φ28

    Φ28

    Load-bearing single wheel size

    mm

    Φ70×80

    Φ80×84

    Load-bearing twin wheel size

    mm

    Φ70×60

    Φ80×60

    Steering wheel size

    mm

    Φ180×50

    Φ180×50

    Minimum turning radius

    mm

    1080/1350/1400

    1080/1350/1400

    Wheel material



    PU/Nylon/Rubber

    PU/Nylon/Rubber

    Self-weight

    Kg

    50-66

    50-66

    *We reserve the right to change product design and specifications without prior notice.
