CDDYG-K Electric Stacker
Modol: CDDYG-K Electric Stacker

Electric stacker with low center of gravity and battery indicator

  • Low centre of gravity design with good stability.
  • Multifunctional display meter with power display, fault code display and cumulative working time display.
  • Battery can be pulled out from the side, convenient for battery interchange and maintenance.
  • Handlebar with emergency reverse switch for safer operation of the whole vehicle.
  • The handlebar is in the braking position both vertically and horizontally to improve the safety of the vehicle.  Integrated hydraulic power unit for more stable and reliable performance.
  • Parameters
  • Assembly Diagram
  • Contact
  • Basic

    Model



    CDDYG-K 1516

    CDDYG-K 1520

    CDDYG-K 1525

    CDDYG-K 1530

    CDDYG-K 1535

    Rated load

    Q(Kg)

    1500

    1500

    1500

    1500

    1500

    Load centre distance

    C(mm)

    450

    450

    450

    450

    450

    Lifting method



    Electric

    Electric

    Electric

    Electric

    Electric

    Operating method



    Walking

    Walking

    Walking

    Walking

    Walking

    Wheels

    Material



    PU

    PU

    PU

    PU

    PU

    Wheelbase (rear/front)

    mm

    475/560

    475/560

    475/560

    475/560

    475/560

    Driving/steering/weight-bearing wheels Quantity



    1×+2/4

    1×+2/4

    1×+2/4

    1×+2/4

    1×+2/4

    Size of load-bearing wheels

    mm

    Φ80×60

    Φ80×60

    Φ80×60

    Φ80×60

    Φ80×60

    Drive wheel size

    mm

    Φ210×75

    Φ210×75

    Φ210×75

    Φ210×75

    Φ210×75

    Counterbalance wheel size

    mm

    Φ125×30

    Φ125×30

    Φ125×30

    Φ125×30

    Φ125×30

    Dimensions

    Minimum fork height from the ground

    h1(mm)

    90

    90

    90

    90

    90

    Maximum fork height after lifting

    h2(mm)

    1600

    2000

    2500

    3000

    3500

    Max. lifting stroke

    mm

    1510

    1910

    2410

    2910

    3410

    Outside fork width

    b3(mm)

    320-740

    320-740

    320-740

    320-740

    320-740

    Inside fork width

    b2(mm)

    20-440

    20-440

    20-440

    20-440

    20-440

    Fork dimensions

    l/e/s(mm)

    1150/150/60

    1150/150/60

    1150/150/60

    1150/150/60

    1150/150/60

    Overall length (incl. handle)

    L1(mm)

    2060

    2060

    2060

    2060

    2060

    Overall width

    B1(mm)

    750

    750

    750

    750

    750

    Overall height

    H1(mm)

    2180

    1630

    1880

    2130

    2380

    Min. turning radius

    Wa(mm)

    1500

    1500

    1500

    1500

    1500

    Aisle width, pallet1000*1200

    mm

    2310

    2310

    2310

    2310

    2310

    Aisle width, pallet800*1200

    mm

    2360

    2360

    2360

    2360

    2360

     Performance

    Max. travel speed (full/no load)

    km/h

    3.5/4

    3.5/4

    3.5/4

    3.5/4

    3.5/4

    Max. lifting speed (full/no load)

    mm/s

    70/100

    70/100

    70/100

    70/100

    70/100

    Max. descent speed (full/no load)

    mm/s

    60/70

    60/70

    60/70

    60/70

    60/70

    Fast/slow speed adjustment function



    Climbing speed (full/no load)

    %

    3.5/4

    3.5/4

    3.5/4

    3.5/4

    3.5/4

    Electrical

    Drive mode



    DC

    DC

    DC

    DC

    DC

    Drive motor

    Kw

    24V/0.75

    24V/0.75

    24V/0.75

    24V/0.75

    24V/0.75

    Lifting motor

    Kw

    24V/2.2

    24V/2.2

    24V/2.2

    24V/2.2

    24V/2.2

    Battery capacity

    V/Ah

    2×12/120

    2×12/120

    2×12/120

    2×12/120

    2×12/120

    Charger type



    24V/12A

    24V/12A

    24V/12A

    24V/12A

    24V/12A

    Weight

    Battery weight

    Kg

    2×28

    2×28

    2×28

    2×28

    2×28

    Self-weight

    Kg

    420

    500

    540

    580

    620

    *We reserve the right to change product design and specifications without prior notice.
